GZ SERIES

Slag crushers are made for crushing slag with the end product’s size up to 50mm. Depending on the feeder’s size one may choose to use a single or a double crushing system.

Capacity

In the crushers manufactured by our company you may find available : single or double crushing system.

Disassembly

Thanks to many years of experience in machines’ construction and repair we were able to design customer friendly crushers easier to assemble and disassemble.

Longer periods between repairs

The GZ crushers we have used state-of-the-art construction materials, which prolong the parts’ lifetime cycle and reduce the machine’s weight. The over-sized bearings applied in our crushers allow for their longer failure-free operation. Crusher’s spare parts are designed to be easily replaced with small lifting devices, which can be supplied as accessories for the slag crusher - Hammer.

Technical data


Crusher Product’s size [mm] Capacity [m3/h] Power [kW] Weight [kg]
GZ-01 single crushing system 0-50 up to 25 11 1350
GZ-02 double crushing system 0-50 up to 25 15 2300
